PIPE SUPPORT BRACKET SINGLE
Material: Stainless Steel or Electrogalvanized
Clamp used to mount on pipe while support brackets used along with U- Bolts for fitting different sizes of pipes. Also available in double brackets with supports brackets on either side of clamp.
Spacers for U bolts provided on request.
| PIPE SUPPORT BRACKET | ||||||
| MODEL | FINISH | CLAMP SIZE | SLIDING LENGTH | |||
| CSB-15-32 | Stainless Steel or Electrogalvanized | 1-1/4" | 150 | |||
| CSB-20-32 | Stainless Steel or Electrogalvanized | 1-1/4" | 200 | |||
| CSB-25-32 | Stainless Steel or Electrogalvanized | 1-1/4" | 250 | |||
| CSB-30-32 | Stainless Steel or Electrogalvanized | 1-1/4" | 300 | |||
| CSB-40-32 | Stainless Steel or Electrogalvanized | 1-1/4" | 400 | |||
| CSB-50-32 | Stainless Steel or Electrogalvanized | 1-1/4" | 500 | |||
| CSB-60-32 | Stainless Steel or Electrogalvanized | 1-1/4" | 600 | |||
| CSB-15-38 | Stainless Steel or Electrogalvanized | 1-1/2" | 150 | |||
| CSB-20-38 | Stainless Steel or Electrogalvanized | 1-1/2" | 200 | |||
| CSB-25-38 | Stainless Steel or Electrogalvanized | 1-1/2" | 250 | |||
| CSB-30-38 | Stainless Steel or Electrogalvanized | 1-1/2" | 300 | |||
| CSB-40-38 | Stainless Steel or Electrogalvanized | 1-1/2" | 400 | |||
| CSB-50-38 | Stainless Steel or Electrogalvanized | 1-1/2" | 500 | |||
| CSB-60-38 | Stainless Steel or Electrogalvanized | 1-1/2" | 600 | |||
| CSB-15-50 | Stainless Steel or Electrogalvanized | 2" | 150 | |||
| CSB-20-50 | Stainless Steel or Electrogalvanized | 2" | 200 | |||
| CSB-25-50 | Stainless Steel or Electrogalvanized | 2" | 250 | |||
| CSB-30-50 | Stainless Steel or Electrogalvanized | 2" | 300 | |||
| CSB-40-50 | Stainless Steel or Electrogalvanized | 2" | 400 | |||
| CSB-50-50 | Stainless Steel or Electrogalvanized | 2" | 500 | |||
| CSB-60-50 | Stainless Steel or Electrogalvanized | 2" | 600 | |||
| CSB-15-63 | Stainless Steel or Electrogalvanized | 2-1/2" | 150 | |||
| CSB-20-63 | Stainless Steel or Electrogalvanized | 2-1/2" | 200 | |||
| CSB-25-63 | Stainless Steel or Electrogalvanized | 2-1/2" | 250 | |||
| CSB-30-63 | Stainless Steel or Electrogalvanized | 2-1/2" | 300 | |||
| CSB-40-63 | Stainless Steel or Electrogalvanized | 2-1/2" | 400 | |||
| CSB-50-63 | Stainless Steel or Electrogalvanized | 2-1/2" | 500 | |||
| CSB-60-63 | Stainless Steel or Electrogalvanized | 2-1/2" | 600 | |||
| CSB-15-76 | Stainless Steel or Electrogalvanized | 3" | 150 | |||
| CSB-20-76 | Stainless Steel or Electrogalvanized | 3" | 200 | |||
| CSB-25-76 | Stainless Steel or Electrogalvanized | 3" | 250 | |||
| CSB-30-76 | Stainless Steel or Electrogalvanized | 3" | 300 | |||
| CSB-40-76 | Stainless Steel or Electrogalvanized | 3" | 400 | |||
| CSB-50-76 | Stainless Steel or Electrogalvanized | 3" | 500 | |||
| CSB-60-76 | Stainless Steel or Electrogalvanized | 3" | 600 | |||
| Custom Sizes Available | ||||||
